GL200 Portable Laser Methane Gas Detector | GasReady

The long-range GL200 Portable Laser Methane Gas Detector delivers ultra-fast 0.1s response from up to 100 meters. Its robust, graph-enabled design ensures maximum safety and efficiency for remote leak inspections.

GL200 Portable Laser Methane Gas Detector | GasReady

The long-range GL200 Portable Laser Methane Gas Detector delivers ultra-fast 0.1s response from up to 100 meters. Its robust, graph-enabled design ensures maximum safety and efficiency for remote leak inspections.

FEATURES

  • Extreme Remote Detection: Enables high-precision methane monitoring from a distance of up to 100 meters, ensuring inspector safety in hazardous areas.

  • Ultra-Fast 0.1s Response: Features cutting-edge laser technology with a millisecond-level response time (0.1s) and high sensitivity for immediate leak identification.

  • Intuitive Visual Analytics: Equipped with a dual-mode color screen that displays both real-time data and trend graphs for simplified site assessment.

  • High-Endurance Industrial Build: Powered by a massive 4000mAh battery and housed in a waterproof, anti-slip casing designed to withstand the most demanding field conditions.

SPECIFICATIONS

Parameter Specifications
Gas Detected Methane (CH₄)
Detection Scope 0 – 50,000 PPM·m
Detection Principle Tunable Laser Absorption Spectroscopy (TDLAS)
Detection Distance 10m Standard (Up to 30m maximum)
Static Detection Limit 5 PPM·m
Response Time Ultra-fast 0.1 Seconds
Indication Mode High-definition LCD for real-time data & system status
Alarm System Audible buzzer, LED visual, and tactile vibration alerts
Working Environment -20°C to 60°C; Humidity ≤90% RH (non-condensing)
Power Supply DC 11.1V (High-capacity 4000mAh lithium battery)
Explosion-Proof Mark Ex ib IIB T4 Gb
Dimensions 240 × 78 × 122 mm
Weight Approx. 600g
